Frame Taps M3

M3 threads are easy to ignore until one fails. On older horizontal-dropout frames, M3×0.5 holds the axle-positioning bolts that set the rear-wheel chainline. On a working frame, an M3 thread also shows up on cable guides, certain disc-brake adapter mounting holes, and the small hardware on internal-routing exit ports. A stripped M3 thread on any of these stops the job until the thread is restored.

The 1695 Frame Tap M3 chases an existing M3×0.5 thread; it doesn't cut a new one. The cutting edges follow the pitch and major-diameter of the existing thread and remove only the paint, corrosion, or distortion that's blocking it. The result is a thread that takes a fresh bolt cleanly without losing the thread's geometry.

When to chase an M3 thread

• After paint overspray at the factory has filled the thread
• After crash damage has bent or distorted the thread profile
• After corrosion or seized-bolt residue has built up in the thread
• Before installing new hardware in a frame that's been in storage

If the thread is genuinely stripped (the bolt has cut new threads into the surrounding metal), chasing won't fix it. The fix there is a thread insert or a Helicoil; different repair, different tool.

Use with the magnetic handle

The 1695 Frame Tap pairs with our magnetic Handle for Pedal Taps 1695/4BI for the leverage to cut cleanly without cross-threading. The magnetic-collet engagement holds the tap square to the work; a standard tap handle works too but the magnetic version stays put under hand-pressure on small-pitch threads.

Specs

• M3×0.5 chase tap
• Hardened tool-steel cutting edges
• Square-shank engagement, compatible with 1695/4BI Handle for Pedal Taps
• Article number: 1695 (M3 size)

For the M5×0.8 size, see our M5 frame tap. For the BSA bottom-bracket shell, see the BSA tap set.

Built in Zreče, Slovenia

Unior has been forging hand tools in Zreče since 1919, and sponsors professional road and mountain-bike race teams. Thread taps are a general-machinist tool that Unior makes for the broader hand-tool catalog and adapts to bike-specific thread sizes for the cycling line. Same hardened tool-steel and same heat-treatment as the rest of the tap family.

Pro tip from our mechanics

The right time to chase a frame thread is the moment a new bolt feels gritty going in, not after it strips. Two minutes with the right-pitch tap before bolting in fresh hardware is the cheapest insurance against a stripped thread an hour later. Our workshop hand tools guide covers thread-chase and other workshop work that quietly saves cranks, frames, and customer trust: Workshop hand tools every bike shop needs →
